Product Details

16 Zones Conventional Fire Alarm Panel E54-2/4. Up to 20 (32 SensoMAG Series) detectors & and unlimited number of call points per zone.

Download datasheet

Rs.68950 Rs.50000

  • Stock: In Stock
  • Category : Conventional Fire Detection & Alarm System
  • SKU : 31020021

Conventional fire alarm control panel, 8 fully monitored fire zones, expandable up to 16 zones ;

MAG8Plus is a conventional fire detection and indication panel certificated to EN54-2/4.

The panel has 8 fixed and is expanded up to 16 zones.MAG8Plus is based on a modular principle – a power unit, a control panel, zone/sounder expanders, an indication module and battery space. A detailed LED indication shows the status of the system. An appropriate mode for zone detector testing by a single person has been implemented – One Man Test. All zones and sirens within the system can be eliminated (Bypass). Relay outputs, associated with each system zone, can also be added to the system with the help of additional MR 8 modules. The panel have been designed to operate with one 12V/ 18Ah battery back-up power, which reduces the costs by the value of one battery per system. The MAG 8 Plus is suitable for vast range of applications – big office buildings, schools, supermarkets and other with space of over 3000m².

Description

  • 8 to 16 zones, expandable
  • Supports up to 512 detectors and unlimited callpoints
  • 4 monitored siren outputs – 300 mA each
  • Double knock mode
  • Siren delay
  • Supports relay expander and LOG module
  • Active EOL allowing continuous monitoring of inputs
  • Levels of access protected by means of key
  • Simple programming by means of jumpers
  • Multi language front panels
  • Plastic box
Main Power Supply~230 VAC ± 10%
Auxiliary output24 VDC/ 0,3A fuse
Back-up Power Supply1 battery, 12V/ 18Ah
Operating temperature-5°C to +40°C
Weight (without battery)~4kg
Dimensions of the metal bottom441x331x80mm
Dimensions of plastic cover461x344x45

* All panels requires a battery backup to function; need to be procured separately. Refer specifications for size.

** Price are subject to change at anytime. Please confirm via email as no payment gateway is connected.

Color White
Origin Europe
Material Plastic
Seller's Warranty 1 Year
